Home Automation System for a Camp with Cellular Internet

Wouldn't it be nice if you could start warming up the camp before you leave the house? How about using Alexa to do it for you!

AdvancedFull instructions provided6 hours11,309
Home Automation System for a Camp with Cellular Internet

Things used in this project

Hardware components

Echo Dot
Amazon Alexa Echo Dot
×1
Arduino MKR1000
Arduino MKR1000
×1
Relay Shield for Particle Photon I²C 8-Channel SPDT 10-Amp
ControlEverything.com Relay Shield for Particle Photon I²C 8-Channel SPDT 10-Amp
This one says its an i2c relay shield, the one I used was just an opto coupler relay shield with 8 input pins.
×1
Hologram Nova
Hologram Nova
×1
Raspberry Pi 2 Model B
Raspberry Pi 2 Model B
×1
USB WiFi Dongle
×1

Story

Read more

Schematics

Sensor wiring diagram

Sensor relay oizmeofsej

Code

sensor_relay.ino

Arduino
This is the arduino code for the sensor.
#include <SPI.h>
#include <WiFi101.h>
#include <WiFiMDNSResponder.h>

#define UDP_TX_PACKET_MAX_SIZE 8192

IPAddress ipMulti(239, 255, 255, 250);
const unsigned int portMulti = 1900;
char packetBuffer[UDP_TX_PACKET_MAX_SIZE];
boolean udpConnected = false;

WiFiUDP Udp;

String persistent_uuid = "1234567890";
String friendlyName = "camp";
boolean relayState = false;
int relayPin = 1;

const int ledPin = 6; // LED pin for connectivity status indicator

char mdnsName[] = "wifi101";

WiFiServer server(80);

// Create a MDNS responder to listen and respond to MDNS name requests.
WiFiMDNSResponder mdnsResponder;

void setup() {
  //Initialize serial:
  Serial.begin(9600);

  pinMode(relayPin, OUTPUT);
  digitalWrite(relayPin, HIGH);
  pinMode(2, OUTPUT);
  digitalWrite(2, HIGH);
  pinMode(3, OUTPUT);
  digitalWrite(3, HIGH);
  pinMode(4, OUTPUT);
  digitalWrite(4, HIGH);
  pinMode(5, OUTPUT);
  digitalWrite(5, HIGH);
  pinMode(6, OUTPUT);
  digitalWrite(6, HIGH);
  pinMode(7, OUTPUT);
  digitalWrite(7, HIGH);
  pinMode(8, OUTPUT);
  digitalWrite(8, HIGH);

  // check for the presence of the shield:
  if (WiFi.status() == WL_NO_SHIELD) {
    Serial.println("WiFi shield not present");
    // don't continue:
    while (true);
  }

  // configure the LED pin for output mode
  pinMode(ledPin, OUTPUT);

  // Start in provisioning mode:
  //  1) This will try to connect to a previously associated access point.
  //  2) If this fails, an access point named "wifi101-XXXX" will be created, where XXXX
  //     is the last 4 digits of the boards MAC address. Once you are connected to the access point,
  //     you can configure an SSID and password by visiting http://wifi101/
 // WiFi.beginProvision();
  WiFi.beginProvision(6);

  while (WiFi.status() != WL_CONNECTED) {
    // wait while not connected

    // blink the led to show an unconnected status
    digitalWrite(ledPin, HIGH);
    delay(500);
    digitalWrite(ledPin, LOW);
    delay(500);
  }

  // connected, make the LED stay on
  digitalWrite(ledPin, HIGH);

  server.begin();

  // Setup the MDNS responder to listen to the configured name.
  // NOTE: You _must_ call this _after_ connecting to the WiFi network and
  // being assigned an IP address.
  if (!mdnsResponder.begin(mdnsName)) {
    Serial.println("Failed to start MDNS responder!");
    while (1);
  }

  Serial.print("Server listening at http://");
  Serial.print(mdnsName);
  Serial.println(".local/");

  // you're connected now, so print out the status:
  printWiFiStatus();

  // only proceed if wifi connection successful
  if (WiFi.status() == WL_CONNECTED) {
    Serial.println("Start UDP server to discover devices");
    udpConnected = connectUDP();

    if (udpConnected) {
      // initialise pins if needed
      startHttpServer();
    }
  }
}

void loop() {
  // Call the update() function on the MDNS responder every loop iteration to
  // make sure it can detect and respond to name requests.
  mdnsResponder.poll();

  startHttpServer();

  if (WiFi.status() == WL_CONNECTED) {
    if (udpConnected) {
      // if there’s data available, read a packet
      int packetSize = Udp.parsePacket();

      if (packetSize) {
        IPAddress remote = Udp.remoteIP();

        for (int i = 0; i < 4; i++) {
          Serial.print(remote[i], DEC);
          if (i < 3) {
            Serial.print(".");
          }
        }

        Serial.print(", port ");
        Serial.println(Udp.remotePort());

        int len = Udp.read(packetBuffer, 255);

        if (len > 0) {
          packetBuffer[len] = 0;
        }

        String request = packetBuffer;
        Serial.println("Request:");
        Serial.println(request);

        if (request.indexOf("M-SEARCH") >= 0) {
          if ((request.indexOf("urn:Belkin:device") > 0) || (request.indexOf("ssdp:all") > 0) || (request.indexOf("upnp:rootdevice") > 0)) {
            Serial.println("Responding to search request ...");
            respondToSearch();
          }
        }
      }
      delay(10);
    }
  } else {
    Serial.println("Cannot connect to Wifi");
  }
}


void printWiFiStatus() {
  // print the SSID of the network you're attached to:
  Serial.print("SSID: ");
  Serial.println(WiFi.SSID());

  // print your WiFi shield's IP address:
  IPAddress ip = WiFi.localIP();
  Serial.print("IP Address: ");
  Serial.println(ip);

  // print the received signal strength:
  long rssi = WiFi.RSSI();
  Serial.print("signal strength (RSSI):");
  Serial.print(rssi);
  Serial.println(" dBm");
}

boolean connectUDP() {
  boolean state = false;

  Serial.println("");
  Serial.println("Connecting to UDP");

  //if(Udp.beginMulticast(WiFi.localIP(), ipMulti, portMulti)) {
  if (Udp.beginMulticast(ipMulti, portMulti)) {
    Serial.println("Connection successful");
    state = true;
  }
  else {
    Serial.println("Connection failed");
  }

  return state;
}

bool beginUdpMulticast() {
  // put your main code here, to run repeatedly:

  boolean state = false;

  Serial.println("Begin multicast ..");

  if (Udp.beginMulticast(ipMulti, portMulti)) {
    Serial.print("Udp multicast server started at ");
    Serial.print(ipMulti);
    Serial.print(":");
    Serial.println(portMulti);

    state = true;
  }
  else {
    Serial.println("Connection failed");
  }

  return state;

}

void serverUdpLoop() {
  int packetSize = Udp.parsePacket();
  if (packetSize <= 0)
    return;

  IPAddress senderIP = Udp.remoteIP();
  unsigned int senderPort = Udp.remotePort();

  // read the packet into the buffer
  Udp.read(packetBuffer, packetSize);

  // check if this is a M-SEARCH for WeMo device
  String request = String((char *)packetBuffer);

  if (request.indexOf('M-SEARCH') >= 0) {
    if ((request.indexOf("urn:Belkin:device:**") > 0) || (request.indexOf("ssdp:all") > 0) || (request.indexOf("upnp:rootdevice") > 0)) {
      Serial.println("Got UDP Belkin Request..");
    }
  }
}
void respondToSearch() {
  Serial.println("");
  Serial.print("Sending response to ");
  Serial.println(Udp.remoteIP());
  Serial.print("Port : ");
  Serial.println(Udp.remotePort());

  IPAddress localIP = WiFi.localIP();
  char s[16];
  sprintf(s, "%d.%d.%d.%d", localIP[0], localIP[1], localIP[2], localIP[3]);

  String response =
    "HTTP/1.1 200 OK\r\n"
    "CACHE-CONTROL: max-age=86400\r\n"
    "DATE: Fri, 15 Apr 2016 04:56:29 GMT\r\n"
    "EXT:\r\n"
    "LOCATION: http://" + String(s) + ":80/setup.xml\r\n"
    "OPT: \"http://schemas.upnp.org/upnp/1/0/\"; ns=01\r\n"
    "01-NLS: b9200ebb-736d-4b93-bf03-835149d13983\r\n"
    "SERVER: Unspecified, UPnP/1.0, Unspecified\r\n"
    "ST: urn:Belkin:device:**\r\n"
    "USN: uuid:" + persistent_uuid + "::urn:Belkin:device:**\r\n"
    "X-User-Agent: redsonic\r\n\r\n";

  // Try changing to this if you have problems discovering
  /*
    String response =
    "HTTP/1.1 200 OK\r\n"
    "CACHE-CONTROL: max-age=86400\r\n"
    "DATE: Fri, 15 Apr 2016 04:56:29 GMT\r\n"
    "EXT:\r\n"
    "LOCATION: http://" + String(s) + ":80/setup.xml\r\n"
    "OPT: "http://schemas.upnp.org/upnp/1/0/\"; ns=01\r\n"
    "01-NLS: b9200ebb-736d-4b93-bf03-835149d13983\r\n"
    "SERVER: Unspecified, UPnP/1.0, Unspecified\r\n"
    "ST: ssdp:all\r\n"
    "USN: uuid:" + persistent_uuid + "::upnp:rootdevice\r\n"
    "X-User-Agent: redsonic\r\n\r\n";
  */

  Udp.beginPacket(Udp.remoteIP(), Udp.remotePort());
  Udp.write(response.c_str());
  Udp.endPacket();

  Serial.println("Response sent !");
}

void startHttpServer() {

  WiFiClient client = server.available();
  if (client) {
    Serial.println("new udp client");
    // an http request ends with a blank line
    boolean currentLineIsBlank = true;
    String request = "";
    String postData = "";
    while (client.connected()) {
      if (client.available()) {
        char c = client.read();
        Serial.write(c);
        request += String(c);
        if (c == '\n' && currentLineIsBlank) {

          break;
        }
        if (c == '\n') {
          // you're starting a new line
          currentLineIsBlank = true;
        }
        else if (c != '\r') {
          // you've gotten a character on the current line
          currentLineIsBlank = false;
        }
      }
    }
    //grab post data if there is any.
    Serial.print("\nBefore Post check: " + request + "\n\n");
    if (request.indexOf("POST") >= 0) {
      int intCL = request.indexOf("Content-Length:");
      int clLen = request.indexOf(String(char(13)), intCL + 1);
      int iContentLength = request.substring(intCL + 16, clLen + 1).toInt();
      //Serial.println("Content Length 2: " + iContentLength);
      for (int i = 0; i <= iContentLength - 1; i++) {
        char c = client.read();
        postData += c;
      }
      Serial.println("Post Data: " + postData);
    }

    Serial.print("New Request: " + request);

    if (request.indexOf("/index.html") > 0) {
      Serial.println("Got Request index.html ...\n");
      client.println("HTTP/1.1 200 OK");
      client.println("Content-Type: text/html");
      //client.println("Transfer-Encoding: chunked");
      client.println("Connection: close");  // the connection will be closed after completion of the response
      client.println();
      client.println("<!DOCTYPE HTML>");
      client.println("<html>");
      // output the value of each analog input pin
      client.println("Hello World!!!");
      client.println("</html>");
      // close the connection:

    }

    if (request.indexOf("/upnp/control/basicevent") > 0) {
      Serial.println("########## Responding to  /upnp/control/basicevent ... ##########");

      if(request.indexOf("basicevent1") > 0) {
        relayPin = 1;
      }
      if(request.indexOf("basicevent2") > 0) {
        relayPin = 2;
      }
      if(request.indexOf("basicevent3") > 0) {
        relayPin = 3;
      }
      if(request.indexOf("basicevent4") > 0) {
        relayPin = 4;
      }
      if(request.indexOf("basicevent5") > 0) {
        relayPin = 5;
      }
      if(request.indexOf("basicevent6") > 0) {
        relayPin = 6;
      }
      if(request.indexOf("basicevent7") > 0) {
        relayPin = 7;
      }
      if(request.indexOf("basicevent8") > 0) {
        relayPin = 8;
      }

      Serial.print("request:");
      Serial.println(postData);

      if (postData.indexOf("SetBinaryState") >= 0) {
        if (postData.indexOf("<BinaryState>1</BinaryState>") >= 0) {
          Serial.println("Got Turn on request");
          turnOnRelay(client);
        }

        if (postData.indexOf("<BinaryState>0</BinaryState>") >= 0) {
          Serial.println("Got Turn off request");
          turnOffRelay(client);
        }
      }

      if (postData.indexOf("GetBinaryState") >= 0) {
        Serial.println("Got binary state request");
        sendRelayState(client);
      }
    }

    if (request.indexOf("/eventservice.xml") > 0) {

      Serial.println(" ########## Responding to eventservice.xml ... ########\n");

      String eventservice_xml = "<scpd xmlns=\"urn:Belkin:service-1-0\">"
                                "<actionList>"
                                "<action>"
                                "<name>SetBinaryState</name>"
                                "<argumentList>"
                                "<argument>"
                                "<retval/>"
                                "<name>BinaryState</name>"
                                "<relatedStateVariable>BinaryState</relatedStateVariable>"
                                "<direction>in</direction>"
                                "</argument>"
                                "</argumentList>"
                                "</action>"
                                "<action>"
                                "<name>GetBinaryState</name>"
                                "<argumentList>"
                                "<argument>"
                                "<retval/>"
                                "<name>BinaryState</name>"
                                "<relatedStateVariable>BinaryState</relatedStateVariable>"
                                "<direction>out</direction>"
                                "</argument>"
                                "</argumentList>"
                                "</action>"
                                "</actionList>"
                                "<serviceStateTable>"
                                "<stateVariable sendEvents=\"yes\">"
                                "<name>BinaryState</name>"
                                "<dataType>Boolean</dataType>"
                                "<defaultValue>0</defaultValue>"
                                "</stateVariable>"
                                "<stateVariable sendEvents=\"yes\">"
                                "<name>level</name>"
                                "<dataType>string</dataType>"
                                "<defaultValue>0</defaultValue>"
                                "</stateVariable>"
                                "</serviceStateTable>"
                                "</scpd>\r\n"
                                "\r\n";

      Serial.println("Got Request /eventservice.xml ...\n");
      client.println("HTTP/1.1 200 OK");
      client.println("Content-Type: text/plain");
      //client.println("Transfer-Encoding: chunked");
      client.println("Connection: close");  // the connection will be closed after completion of the response
      client.println();
      // output the value of each analog input pin
      client.println(eventservice_xml);
    }

    if (request.indexOf("/setup.xml") > 0) {
      Serial.println(" ########## Responding to setup.xml ... ########\n");

      IPAddress localIP = WiFi.localIP();
      char s[16];
      sprintf(s, "%d.%d.%d.%d", localIP[0], localIP[1], localIP[2], localIP[3]);

      String setup_xml = "<?xml version=\"1.0\"?>"
                         "<root>"
                         "<device>"
                         "<deviceType>urn:Belkin:device:controllee:1</deviceType>"
                         "<friendlyName>" + friendlyName + "</friendlyName>"
                         "<manufacturer>Belkin International Inc.</manufacturer>"
                         "<modelName>Socket</modelName>"
                         "<modelNumber>3.1415</modelNumber>"
                         "<modelDescription>Belkin Plugin Socket 1.0</modelDescription>\r\n"
                         "<UDN>uuid:" + persistent_uuid + "</UDN>"
                         "<serialNumber>221517K0101769</serialNumber>"
                         "<binaryState>0</binaryState>"
                         "<serviceList>"
                         "<service>"
                         "<serviceType>urn:Belkin:service:basicevent:1</serviceType>"
                         "<serviceId>urn:Belkin:serviceId:basicevent1</serviceId>"
                         "<controlURL>/upnp/control/basicevent1</controlURL>"
                         "<eventSubURL>/upnp/event/basicevent1</eventSubURL>"
                         "<SCPDURL>/eventservice.xml</SCPDURL>"
                         "</service>"

                         "<service>"
                         "<serviceType>urn:Belkin:service:basicevent:2</serviceType>"
                         "<serviceId>urn:Belkin:serviceId:basicevent2</serviceId>"
                         "<controlURL>/upnp/control/basicevent2</controlURL>"
                         "<eventSubURL>/upnp/event/basicevent2</eventSubURL>"
                         "<SCPDURL>/eventservice.xml</SCPDURL>"
                         "</service>"
                         "<service>"
                         "<serviceType>urn:Belkin:service:basicevent:3</serviceType>"
                         "<serviceId>urn:Belkin:serviceId:basicevent3</serviceId>"
                         "<controlURL>/upnp/control/basicevent3</controlURL>"
                         "<eventSubURL>/upnp/event/basicevent3</eventSubURL>"
                         "<SCPDURL>/eventservice.xml</SCPDURL>"
                         "</service>"
                         "<service>"
                         "<serviceType>urn:Belkin:service:basicevent:4</serviceType>"
                         "<serviceId>urn:Belkin:serviceId:basicevent4</serviceId>"
                         "<controlURL>/upnp/control/basicevent4</controlURL>"
                         "<eventSubURL>/upnp/event/basicevent4</eventSubURL>"
                         "<SCPDURL>/eventservice.xml</SCPDURL>"
                         "</service>"
                         "</serviceList>"
                         "</device>"
                         "</root>\r\n"
                         "\r\n";

      Serial.println("Got Request /setup.xml ...\n");
      client.println("HTTP/1.1 200 OK");
      client.println("Content-Type: text/xml");
      //client.println("Transfer-Encoding: chunked");
      client.println("Connection: close");  // the connection will be closed after completion of the response
      client.println();
      client.println(setup_xml);
      Serial.print("Sending :");
      Serial.println(setup_xml);
    }

    if (request.indexOf("/on.html") > 0) {
      Serial.println(" ########## Responding to on.html ... ########\n");
      Serial.println("Got Request /on.html ...\n");
      Serial.println("Got Turn on request");

      turnOnRelay(client);
    }

    if (request.indexOf("/off.html") > 0) {
      Serial.println(" ########## Responding to off.html ... ########\n");
      Serial.println("Got Request /off.html ...\n");
      Serial.println("Got Turn off request");

      turnOffRelay(client);
    }

    if (request.indexOf("/status.html") > 0) {
      Serial.println(" ########## Responding to status.html ... ########\n");
      Serial.println("Got Request /status.html ...\n");
      client.println("HTTP/1.1 200 OK");
      client.println("Content-Type: text/plain");
      //client.println("Transfer-Encoding: chunked");
      client.println("Connection: close");  // the connection will be closed after completion of the response
      client.println();
      String statrespone = "0";
      if (relayState) {
        statrespone = "1";
      }
      client.println(statrespone);

      Serial.println("Got status request");

    }
    client.stop();
    Serial.println("client disonnected");
  }
}

void turnOnRelay(WiFiClient client) {
  digitalWrite(relayPin, LOW); // turn on relay with voltage LOW
  relayState = true;

  String body =
    "<s:Envelope xmlns:s=\"http://schemas.xmlsoap.org/soap/envelope/\" s:encodingStyle=\"http://schemas.xmlsoap.org/soap/encoding/\"><s:Body>\r\n"
    "<u:SetBinaryStateResponse xmlns:u=\"urn:Belkin:service:basicevent:1\">\r\n"
    "<BinaryState>1</BinaryState>\r\n"
    "</u:SetBinaryStateResponse>\r\n"
    "</s:Body> </s:Envelope>";

  client.println("HTTP/1.1 200 OK");
  client.println("Content-Type: text/xml");
  client.println("gzip: true");
  //client.println("Transfer-Encoding: chunked");
  client.println("Connection: close");  // the connection will be closed after completion of the response
  client.println();
  client.println(body);
  Serial.print("Sending :");
  Serial.println(body);
}

void turnOffRelay(WiFiClient client) {
  digitalWrite(relayPin, HIGH);  // turn off relay with voltage HIGH
  relayState = false;

  String body =
    "<s:Envelope xmlns:s=\"http://schemas.xmlsoap.org/soap/envelope/\" s:encodingStyle=\"http://schemas.xmlsoap.org/soap/encoding/\"><s:Body>\r\n"
    "<u:SetBinaryStateResponse xmlns:u=\"urn:Belkin:service:basicevent:1\">\r\n"
    "<BinaryState>0</BinaryState>\r\n"
    "</u:SetBinaryStateResponse>\r\n"
    "</s:Body> </s:Envelope>";

  client.println("HTTP/1.1 200 OK");
  client.println("Content-Type: text/xml");
  client.println("gzip: true");
  //client.println("Transfer-Encoding: chunked");
  client.println("Connection: close");  // the connection will be closed after completion of the response
  client.println();
  client.println(body);
  Serial.print("Sending :");
  Serial.println(body);
}

void sendRelayState(WiFiClient client) {
  String body =
    "<s:Envelope xmlns:s=\"http://schemas.xmlsoap.org/soap/envelope/\" s:encodingStyle=\"http://schemas.xmlsoap.org/soap/encoding/\"><s:Body>\r\n"
    "<u:GetBinaryStateResponse xmlns:u=\"urn:Belkin:service:basicevent:1\">\r\n"
    "<BinaryState>";

  body += (relayState ? "1" : "0");

  body += "</BinaryState>\r\n"
          "</u:GetBinaryStateResponse>\r\n"
          "</s:Body> </s:Envelope>\r\n";

  client.println("HTTP/1.1 200 OK");
  client.println("Content-Type: text/xml");
  //client.println("Transfer-Encoding: chunked");
  client.println("Connection: close");  // the connection will be closed after completion of the response
  client.println();
  client.println(body);
}

Node Red Flow

JSON
Import this flow into your node-red. make sure you update the html nodes with your ip of the sensor. And in the Alexa nodes, make sure you update the credentials for your login you create in the alexa bridge.
[
    {
        "id": "8501e66.3bee118",
        "type": "http request",
        "z": "dbe65262.fdb3",
        "name": "",
        "method": "POST",
        "ret": "txt",
        "url": "http://your_sensor_ip:80/upnp/control/basicevent1",
        "tls": "",
        "x": 1770,
        "y": 340,
        "wires": [
            [
                "859e01c.4dcb6",
                "e7f0f559.4a79e8"
            ]
        ]
    },
    {
        "id": "607cfc83.e9fb64",
        "type": "inject",
        "z": "dbe65262.fdb3",
        "name": "Relay 1 On",
        "topic": "",
        "payload": "true",
        "payloadType": "bool",
        "repeat": "",
        "crontab": "",
        "once": false,
        "onceDelay": 0.1,
        "x": 1200,
        "y": 400,
        "wires": [
            [
                "5ab03b5c.8181d4"
            ]
        ]
    },
    {
        "id": "8614648e.9886e8",
        "type": "debug",
        "z": "dbe65262.fdb3",
        "name": "",
        "active": false,
        "tosidebar": true,
        "console": false,
        "tostatus": false,
        "complete": "false",
        "x": 2010,
        "y": 540,
        "wires": []
    },
    {
        "id": "cb082e4e.cea0d",
        "type": "inject",
        "z": "dbe65262.fdb3",
        "name": "Relay 1 Off",
        "topic": "",
        "payload": "false",
        "payloadType": "bool",
        "repeat": "",
        "crontab": "",
        "once": false,
        "onceDelay": 0.1,
        "x": 1200,
        "y": 460,
        "wires": [
            [
                "5ab03b5c.8181d4"
            ]
        ]
    },
    {
        "id": "cf07e15c.c5367",
        "type": "inject",
        "z": "dbe65262.fdb3",
        "name": "Relay 1 Status",
        "topic": "",
        "payload": "<?xml version=\"1.0\" encoding=\"utf-8\"?> <s:Envelope xmlns:s=\"http://schemas.xmlsoap.org/soap/envelope/\" s:encodingStyle=\"http://schemas.xmlsoap.org/soap/encoding/\">   <s:Body>     <u:GetBinaryState xmlns:u=\"urn:Belkin:service:basicevent:1\"></u:GetBinaryState>   </s:Body> </s:Envelope>",
        "payloadType": "str",
        "repeat": "",
        "crontab": "",
        "once": false,
        "onceDelay": 0.1,
        "x": 1180,
        "y": 520,
        "wires": [
            [
                "8501e66.3bee118"
            ]
        ]
    },
    {
        "id": "e2ad0877.1bb528",
        "type": "inject",
        "z": "dbe65262.fdb3",
        "name": "Relay 2 on",
        "topic": "",
        "payload": "true",
        "payloadType": "bool",
        "repeat": "",
        "crontab": "",
        "once": false,
        "onceDelay": 0.1,
        "x": 1200,
        "y": 660,
        "wires": [
            [
                "6ddb0a38.77d0c4"
            ]
        ]
    },
    {
        "id": "8d4959c8.841058",
        "type": "inject",
        "z": "dbe65262.fdb3",
        "name": "Relay 2 Off",
        "topic": "",
        "payload": "false",
        "payloadType": "bool",
        "repeat": "",
        "crontab": "",
        "once": false,
        "onceDelay": 0.1,
        "x": 1200,
        "y": 720,
        "wires": [
            [
                "6ddb0a38.77d0c4"
            ]
        ]
    },
    {
        "id": "abc8bca0.ae4a7",
        "type": "http request",
        "z": "dbe65262.fdb3",
        "name": "",
        "method": "POST",
        "ret": "txt",
        "url": "http://your_sensor_ip:80/upnp/control/basicevent2",
        "tls": "",
        "x": 1770,
        "y": 600,
        "wires": [
            [
                "8614648e.9886e8",
                "e7f0f559.4a79e8"
            ]
        ]
    },
    {
        "id": "5711eb3.d68b914",
        "type": "alexa-home",
        "z": "dbe65262.fdb3",
        "conf": "28c11097.692d3",
        "device": "16099",
        "acknoledge": true,
        "name": "Kitchen Light",
        "topic": "",
        "x": 1190,
        "y": 340,
        "wires": [
            [
                "5ab03b5c.8181d4",
                "dbf4dd9d.6fe8a"
            ]
        ]
    },
    {
        "id": "dbf4dd9d.6fe8a",
        "type": "debug",
        "z": "dbe65262.fdb3",
        "name": "",
        "active": true,
        "tosidebar": true,
        "console": false,
        "tostatus": false,
        "complete": "false",
        "x": 1410,
        "y": 260,
        "wires": []
    },
    {
        "id": "5ab03b5c.8181d4",
        "type": "switch",
        "z": "dbe65262.fdb3",
        "name": "",
        "property": "payload",
        "propertyType": "msg",
        "rules": [
            {
                "t": "eq",
                "v": "1",
                "vt": "str"
            },
            {
                "t": "eq",
                "v": "0",
                "vt": "str"
            }
        ],
        "checkall": "true",
        "repair": false,
        "outputs": 2,
        "x": 1390,
        "y": 340,
        "wires": [
            [
                "a70930e7.ccab9"
            ],
            [
                "e5ae59e5.547188"
            ]
        ]
    },
    {
        "id": "7735f9d3.78be58",
        "type": "debug",
        "z": "dbe65262.fdb3",
        "name": "",
        "active": false,
        "tosidebar": true,
        "console": false,
        "tostatus": false,
        "complete": "false",
        "x": 2210,
        "y": 260,
        "wires": []
    },
    {
        "id": "e354e432.8e4db8",
        "type": "alexa-home-resp",
        "z": "dbe65262.fdb3",
        "x": 2240,
        "y": 340,
        "wires": []
    },
    {
        "id": "859e01c.4dcb6",
        "type": "debug",
        "z": "dbe65262.fdb3",
        "name": "",
        "active": false,
        "tosidebar": true,
        "console": false,
        "tostatus": false,
        "complete": "false",
        "x": 2010,
        "y": 260,
        "wires": []
    },
    {
        "id": "e5ae59e5.547188",
        "type": "function",
        "z": "dbe65262.fdb3",
        "name": "Off",
        "func": "msg.payload = '<?xml version=\"1.0\" encoding=\"utf-8\"?> <s:Envelope xmlns:s=\"http://schemas.xmlsoap.org/soap/envelope/\" s:encodingStyle=\"http://schemas.xmlsoap.org/soap/encoding/\">   <s:Body>     <u:SetBinaryState xmlns:u=\"urn:Belkin:service:basicevent:1\">       <BinaryState>0</BinaryState>     </u:SetBinaryState>   </s:Body> </s:Envelope>'\nmsg.headers = {};\nmsg.headers['content-type'] = 'application/xml';\nreturn msg;\n",
        "outputs": 1,
        "noerr": 0,
        "x": 1570,
        "y": 360,
        "wires": [
            [
                "8501e66.3bee118"
            ]
        ]
    },
    {
        "id": "a70930e7.ccab9",
        "type": "function",
        "z": "dbe65262.fdb3",
        "name": "On",
        "func": "msg.payload = '<?xml version=\"1.0\" encoding=\"utf-8\"?> <s:Envelope xmlns:s=\"http://schemas.xmlsoap.org/soap/envelope/\" s:encodingStyle=\"http://schemas.xmlsoap.org/soap/encoding/\">   <s:Body>     <u:SetBinaryState xmlns:u=\"urn:Belkin:service:basicevent:1\">       <BinaryState>1</BinaryState>     </u:SetBinaryState>   </s:Body> </s:Envelope>'\nmsg.headers = {};\nmsg.headers['content-type'] = 'application/xml';\nreturn msg;",
        "outputs": 1,
        "noerr": 0,
        "x": 1570,
        "y": 320,
        "wires": [
            [
                "8501e66.3bee118"
            ]
        ]
    },
    {
        "id": "e7f0f559.4a79e8",
        "type": "function",
        "z": "dbe65262.fdb3",
        "name": "Alexa response",
        "func": "msg.payload = true;\nreturn msg;",
        "outputs": 1,
        "noerr": 0,
        "x": 2020,
        "y": 340,
        "wires": [
            [
                "e354e432.8e4db8",
                "7735f9d3.78be58"
            ]
        ]
    },
    {
        "id": "3ab2c03c.879db",
        "type": "alexa-home",
        "z": "dbe65262.fdb3",
        "conf": "28c11097.692d3",
        "device": "16100",
        "acknoledge": true,
        "name": "Outside Lights",
        "topic": "",
        "x": 1190,
        "y": 600,
        "wires": [
            [
                "6ddb0a38.77d0c4"
            ]
        ]
    },
    {
        "id": "6ddb0a38.77d0c4",
        "type": "switch",
        "z": "dbe65262.fdb3",
        "name": "",
        "property": "payload",
        "propertyType": "msg",
        "rules": [
            {
                "t": "eq",
                "v": "1",
                "vt": "str"
            },
            {
                "t": "eq",
                "v": "0",
                "vt": "str"
            }
        ],
        "checkall": "true",
        "repair": false,
        "outputs": 2,
        "x": 1390,
        "y": 600,
        "wires": [
            [
                "7118df30.b9565"
            ],
            [
                "92240a0c.debd18"
            ]
        ]
    },
    {
        "id": "7118df30.b9565",
        "type": "function",
        "z": "dbe65262.fdb3",
        "name": "On",
        "func": "msg.payload = '<?xml version=\"1.0\" encoding=\"utf-8\"?> <s:Envelope xmlns:s=\"http://schemas.xmlsoap.org/soap/envelope/\" s:encodingStyle=\"http://schemas.xmlsoap.org/soap/encoding/\">   <s:Body>     <u:SetBinaryState xmlns:u=\"urn:Belkin:service:basicevent:1\">       <BinaryState>1</BinaryState>     </u:SetBinaryState>   </s:Body> </s:Envelope>'\nmsg.headers = {};\nmsg.headers['content-type'] = 'application/xml';\nreturn msg;",
        "outputs": 1,
        "noerr": 0,
        "x": 1570,
        "y": 580,
        "wires": [
            [
                "abc8bca0.ae4a7"
            ]
        ]
    },
    {
        "id": "92240a0c.debd18",
        "type": "function",
        "z": "dbe65262.fdb3",
        "name": "Off",
        "func": "msg.payload = '<?xml version=\"1.0\" encoding=\"utf-8\"?> <s:Envelope xmlns:s=\"http://schemas.xmlsoap.org/soap/envelope/\" s:encodingStyle=\"http://schemas.xmlsoap.org/soap/encoding/\">   <s:Body>     <u:SetBinaryState xmlns:u=\"urn:Belkin:service:basicevent:1\">       <BinaryState>0</BinaryState>     </u:SetBinaryState>   </s:Body> </s:Envelope>'\nmsg.headers = {};\nmsg.headers['content-type'] = 'application/xml';\nreturn msg;",
        "outputs": 1,
        "noerr": 0,
        "x": 1570,
        "y": 620,
        "wires": [
            [
                "abc8bca0.ae4a7"
            ]
        ]
    },
    {
        "id": "28c11097.692d3",
        "type": "alexa-home-conf",
        "z": "",
        "username": "your_username"
    }
]

Credits

Dana Mah

Dana Mah

5 projects • 11 followers
I'm a hobbyist interested in microcontroller solutions to simple problems.
Contact

Comments

Add projectSign up / Login
